Lucius e Baer CC12MMS-ENZ - TFT-Ersatzmonitor
12" TFT Industriemonitor als Ersatz für den 12" CRT Farbmonitor Lucius und Baer CC12MMS - ENZEmpfänger :
* Pflichtfelder
oder Abbrechen
Lucius e Baer CC12MMS-ENZ - TFT-Ersatzmonitor
12" TFT Industriemonitor als Ersatz für den 12" CRT Farbmonitor Lucius und Baer CC12MMS - ENZFor questions regarding an order, thank you use the contact form
* Required fields
Cancel or
This 12“ TFT monitor has been developed as a replacement for the 12“ CRT Color Monitor mounted in Lucius e Baer CC12MMS - ENZ.
Our TFT is a Plug & Play solution, that means it is 100% compatible on the electrical and mechanical side.
This allows a quick and easy replacing without a specific technical knowledge and tooling.
Technical data: |
|
Operator panel / CNC |
12” TFT Lucius e Baer CC12MMS-ENZ |
Display |
15“ TFT LCD active matrix / 800x600 |
Brightness |
300 cd/m2 |
Viewing angle |
140° H - 110° V |
Frequency range |
15-45 kHz horizontal, 50-75 Hz vertikal |
Connector |
HD-15 M |
Menu settings |
Via OSD (On Screen Display) |
Front panel |
Frontal Lexan Protection |
Mechanical dimension |
100% compatible to the original |
Operating voltage |
110 - 220 VAC |
Operating temperature |
-10°C to 55°C |
Manufactured according to |
EN55022, EN55024 |
Product code: |
TDI12LC1-B579 |
