TFT Replacement monitor Eaton IDT 45PK PM4000

View larger

Eaton IDT 45PK PM4000 - TFT-Ersatzmonitor

Model TOI8LB1-A435

Condition New

8" TFT Industriemonitor als Ersatz für den 10" CRT Color Monitor verbaut in Eaton IDT 45PK PM4000

An einen Freund senden

An einen Freund senden

Eaton IDT 45PK PM4000 - TFT-Ersatzmonitor
8" TFT Industriemonitor als Ersatz für den 10" CRT Color Monitor verbaut in Eaton IDT 45PK PM4000

Empfänger :

Name Ihrer/es Freundin/es ^* :

E-Mailadresse Ihres Freundes ^* :

^* Pflichtfelder

oder Abbrechen

More info

This 8“ TFT monitor has been developed as a replacement for the 10“ CRT Color Monitor mounted in Eaton IDT 45PK PM4000 Power Series Cuttler Hammer IDT.

Our TFT is a Plug & Play solution, that means it is 100% compatible on the electrical and mechanical side.

This allows a quick and easy replacing without a specific technical knowledge and tooling.

Technical data:
Operator panel / CNC	Eaton IDT 45PK PM4000 Power Series Cuttler Hammer IDT
Original Monitor Code	91-00935-00
Display	8“ TFT LCD active matrix / 800x600
Brightness	300 cd/m2
Viewing angle	140° H - 120° V
Frequency range	15-45 kHz horizontal, 50-75 Hz vertikal
Connector	IDC 10 PIN F
Menu settings	Via OSD (On Screen Display)
Front panel	Frontal Lexan Protection
Mechanical dimension	100% compatible to the original
Operating voltage	100 - 240 VAC
Operating temperature	-10°C to 55°C
Manufactured according to	EN55022, EN55024

Product code:	TOI8LB1-A435
