TFT Replacement monitor Unipo Philips 3460 View larger

Philips 3460 - TFT-Ersatzmonitor

TOI10LB2-B134

New

10" TFT Industriemonitor als Ersatz für den 12" CRT Monitor verbaut in Philips 3460

More details

More info



This 10“ TFT monitor has been developed as a replacement for the 12“ CRT  Monitor mounted in Philips 3460.

Our TFT is a Plug & Play solution,  that means it is 100% compatible on the electrical and mechanical side.

This allows a quick and easy replacing without a specific technical knowledge and tooling.



Technical data:

Operator panel / CNC

Philips 3460

Monitor Code

 2M2812XCTX01 - FIMI 3119 208 89859 - 2M2812XCTX00.

Display

10“ TFT LCD active matrix / 800x600

Brightness

300 cd/m2

Viewing angle

120° H - 90° V

Frequency range

15-45 KHz horizontal, 50-75 KHz vertikal

Connector

CARD-EDGE / BNC / RCA

Menu settings

Via OSD (On Screen Display)

Front panel

Frontal Lexan Protection

Mechanical dimension

100% compatible to the original

Operating voltage

100 - 240 Vac

Operating temperature

-10°C to 55°C

Manufactured according to

EN55022, EN55024



Product code:

TOI10LB2-B134
