IP68 Industrie-Tastatur mit Touchpad

Foil-covered aluminum front plate is mounted flush with durable polyester withstand to most chemicals and liquids under the harshest environments, integrated sealed & ruggedized touchpad. All language versions are available on request (QWERTY - AZERTY).

MECHANICAL DATA:

Number of Keys: 108

Key switch Technology: metal dome key switch technology with short travel keys

Actuation Force: 1.0N for key 13.0mm x 13.0mm (press point)

Key Travel: 0.45mm

Key switch Lifetime: 3 mil. operations

Protection Level: IP68, NEMA 4x

Mounting Type: stand alone mounting desk top .

Operating Temperature: -20 °C to +50 °C;

Colors: 4 (Blue, white, grey, black)

G.W.: 1.30KGs

Key Dimensions (print area): 13.0mm x 13.0mm

Dimensions: 396.0mm x 150.0mm x 27.0mm (L x W x H)

TOUCHPAD:

Touchpad cover: Composite

Motion Detection

Method: capacitive

Resolution: 40 counts / mm

More than Lifetime 10 million strokes

Mutual Capacitance sensing

X/Y position sensing resolution: 40 counts/mm

X/Y position reporting: Relative

Output (self-detectable depending on cable): PS2 or USB

Tracking speed: Maximum 1,016 m/sec

Power supply voltage: 5 V DC ±0.25V

Current rating (active mode): 17 mA

ELECTRICAL DATA:

Supply Voltage: +5V DC +/- 5%

Current Rating: appr. 30mA

EMC Standard: IEC 61000-4-2:2008；IEC 61000-4-3:2006+AI:2007+A2:2010；IEC 61000-4-4:2004

EMI: EN 55022: 2010

EMS: EN 55024:2010

Lifespan > 3 years

Interface: PS2, USB available.

OS: All windows, Linux, Unit, Mac OSX

RELIABILITY:

RoHS , CE, FCC, ESD

Protection Level: IP68

Key Lifespan >3 million actuations

Touchpad lifespan > 10 million of times

MTBF >50000H

MTTR <30min
