IP65 Industrietastatur aus Edelstahl, mit Trackball
Industrietastatur aus Edelstahl, mit 66 Tasten, im kompakten Format, geschützt nach IP65 geschützt und einschließlich eines statischen 38.0mm (mechanischen) Trackball (400 DPI -Auflösung). Metall-Kuppel PCB, mit Gold-auf-Gold-Schlüsselschalter-Technologie, mit kurzem Hub ( 0,45 mm ).Empfänger :
* Pflichtfelder
oder Abbrechen
IP65 Industrietastatur aus Edelstahl, mit Trackball
Industrietastatur aus Edelstahl, mit 66 Tasten, im kompakten Format, geschützt nach IP65 geschützt und einschließlich eines statischen 38.0mm (mechanischen) Trackball (400 DPI -Auflösung). Metall-Kuppel PCB, mit Gold-auf-Gold-Schlüsselschalter-Technologie, mit kurzem Hub ( 0,45 mm ).For questions regarding an order, thank you use the contact form
* Required fields
Cancel or
MECHANICAL DATA:
Actuator/keys: 66 keys, 2.0mm thickness super quality SUS304 brushed stainless steel flat key.
Key top style: Non‐protuberant rectangular keys, laser engraved & etched legends & raised braille on keys are
available
Key Size: 14.0mm x 14.0mm for normal keys, 14.0mm x 28.0mm for enter key, 14.0mm x 100.0mm for space bar.
Key travel: 0.45mm
Actuation Force: 2.0N+/‐0.1N for key 14.0mm x 14.0mm (pressure point) 4.0N+/‐0.1N for key 14.0mm x 28.0mm
(pressure point)
Switch life: more than 5 million of operations.
Front Plate: 1.5mm thickness super quality brushed stainless steel
Back Plate:3.0mm thickness brushed & oxidized aluminium
Tracker ball: 38.1mm (1.5’) diameter, IP65 static 400DPI mechanical trackball, IP68 dynamic washable 800DPI optical
trackball, IP68 dynamic 1200DPI laser trackball are all available.
G.W.: 2.00KGs
Dimensions:361.0mm x 125.0mm (L x W )
ELECTRICAL DATA:
Supply Voltage: +5V DC +/‐5%
Current Rating: appr. 30mA
EMC Standard: It is compliance with the council EMC directive 89/336/EEC
EN55022: 1988+A1:2000+A2:2003
EN55024: 1988+A1:2001+A2:2003
Emission: EN 50081‐1
Immunity: EN 50082‐1
Lifespan > 5 years
Switch Contact Material: metal dome PCB with Gold‐on‐Gold key switch technology
Interface: PS2, USB available.
OS: DOS/Windows95/98/NT/ME/2000/2003/XP/Vista/WIN7, Linux, Unix, Mac OSX
ENVIRONMENTAL ADAPTABILITY:
Operating temperature:‐20oC to +60oC
Storage temperature: ‐30oC to +70oC
Operating RH: 30‐90%
Atmospheric pressure: 60‐106Kpa.
Saline mist: 96 hours, IEC 60512‐6
Damp heat test at + 40oC: 21 days, IEC 60512‐6
Dry heat test at + 85oC: 10 days, IEC 60512‐6
RELIABILITY:
RoHS Compliant, CE and FCC, ESD
Protection Level: IP65(front panel)
Vandal resistant IK10
Key Lifespan >5 million actuations
MTBF >50000H
MTTR <30min
