PNI10CE2
New
Availability date:
10" Lizard Edelstahl-Panel PC, frontal geschützt nach IP65
10,4" Lizard Edelstahl-Panel PC, frontal geschützt nach IP65, speziell entwickelt für hohe hygienische Anforderungen, wie sie z.B. in der Lebensmittel-, Chemie-, oder Pharmaindustrie vorkommen.Empfänger :
* Pflichtfelder
oder Abbrechen
10" Lizard Edelstahl-Panel PC, frontal geschützt nach IP65
10,4" Lizard Edelstahl-Panel PC, frontal geschützt nach IP65, speziell entwickelt für hohe hygienische Anforderungen, wie sie z.B. in der Lebensmittel-, Chemie-, oder Pharmaindustrie vorkommen.For questions regarding an order, thank you use the contact form
* Required fields
Cancel or
Technical data: |
|
Lcd |
10.4” SVGA / Pixel Resolution 800x600 |
Brightness |
350 cd/m2 |
Viewing Angle |
120° H - 90° V |
Connector |
1 x PS2 / 3 x RS-232 / 1 x RS-422/485 / 1 x LAN / 2 x USB / 1 x VGA / AUDIO |
Optional Connector |
LPT |
Touch Screen |
Resistive |
Power Supply |
12 VDC |
Operating Voltage |
0 °C - 55°C |
Case / IP Class |
Frontal IP65 |
Standard Plate |
Inox AISI 304 (V2A) |
Cpu available |
Intel® Atom Processor N270 - 1.6GHz |
Chipset |
GM 945 |
Memory |
2 Gb DDR2 SO-DIMM |
Storage |
2,5" HDD - SSD Modules |
Expansion Bus |
PCI - PCI-e X16 |
Operating System |
- Windows XP pro for Embedded - Windows 7 for Embedded - Windows Embedded Standard 7 - Windows XP Embedded - Embedded Linux, Real-time Kernel
|
Options |
- CPU Intel® Celeron M Processor 1GHz - Fanless - CPU AMD® LX 800 Processors 500 MHz - Fanless - Touch screen : Glas-Film-Glas (GFG), PCT Multitouch - Extended Temperature Range up to -20° C - 70 °C - WIFI - Optional resolution: 1024x768 - Power Supply : 24 VDC, 9-27 VDC / 100-240 VAC with external adapter - Optional Plate : Inox AISI 316 (V4A)
|
|
|
Product code: |
PNI10CE2
|
