TFT Replacement Monitor Fanuc A61L-0001-0093 View larger

Fanuc A61L-0001-0093 - TFT-Ersatzmonitor

TOI8LB3-A756

New

8" TFT Industriemonitor als Ersatz für den 9" CRT Farbmonitor verbaut in Fanuc Fanuc 18M/18T A61L-0001-0093

More details

More info



This 8“ TFT monitor has been developed as a replacement for the 9“ CRT Color Monitor mounted in A61L-0001-0093  .

Our TFT is a Plug & Play solution,  that means it is 100% compatible on the electrical and mechanical side.

This allows a quick and easy replacing without a specific technical knowledge and tooling.





Technical data:

Operator panel / CNC

Fanuc 18M/18T

Original Monitor Code

Fanuc A61L-0001-0093

Display

8“ TFT LCD active matrix / 800x600

Brightness

300 cd/m2

Viewing angle

140° H - 120° V

Frequency range

15-45 kHz horizontal, 50-75 Hz vertikal

Connector

HONDA 20 PIN

Menu settings

Via OSD (On Screen Display)

Front panel

Frontal Lexan Protection

Mechanical dimension

100% compatible to the original

Operating voltage

12 VDC

Operating temperature

-10°C to 55°C

Manufactured according to

EN55022, EN55024



Product code:

TOI8LB3-A756
