TFT monitor for Num 1040-1060 (24 VDC) View larger

Num 1040-1060 (24 VDC) - TFT-Ersatzmonitor

TOE8DB3-A754

New

8" TFT Industriemonitor als Ersatz für den 10" CRT Farbmonitor verbaut in Num 1040-1060 24 VDC.

More details

More info



This 8“ TFT monitor has been developed as a replacement for the 10“ CRT Color Monitor mounted in Num 1040-1060 24 VDC.

Our TFT is a Plug & Play solution,  that means it is 100% compatible on the electrical and mechanical side.

This allows a quick and easy replacing without a specific technical knowledge and tooling.



Technical data:

Operator panel / CNC

1040-1060 24 VDC

Original Monitor Code

LCD NUM0209206209

Display

8“ TFT LCD active matrix / 800x600

Brightness

300 cd/m2

Viewing angle

140° H - 110° V

Frequency range

15-45 kHz horizontal, 50-75 Hz vertikal

Connector

HD 15 M

Menu settings

Via OSD (On Screen Display)

Front panel

Frontal Lexan Protection

Mechanical dimension

100% compatible to the original

Operating voltage

110 - 220 Vac

Operating temperature

-10°C to 55°C

Manufactured according to

EN55022, EN55024



Product code:

TOE12DB3-A272
