TFT Replacement monitor Siemens MP30 View larger

Siemens MP30 - TFT-Ersatzmonitor

TRI17LD1-A767

New

17" TFT Industriemonitor als Ersatz für den 19" CRT Monitor verbaut in Siemens MP30

More details

More info





This 17“ TFT monitor has been developed as a replacement for the 19“ CRT Monitor mounted in Philips MP30.

Our TFT is a Plug & Play solution,  that means it is 100% compatible on the electrical and mechanical side.

This allows a quick and easy replacing without a specific technical knowledge and tooling.



Technical data:

Operator panel / CNC

Siemens MP30

Original Monitor Code

SIEMENS 6AV5030 1DL20-0AC0 - MP30-LCD E XICOM MOD. 3015 - P/N 139001/001

Display

17“ TFT LCD active matrix / 800x600

Brightness

300 cd/m2

Viewing angle

140° H - 110° V

Frequency range

15-45 kHz horizontal, 50-75 Hz vertikal

Connector

 BNC

Menu settings

Via OSD (On Screen Display)

Front panel

Frontal Lexan Protection , Front Panel

Mechanical dimension

100% compatible to the original

Operating voltage

100 - 240 VAC

Operating temperature

-10°C to 55°C

Manufactured according to

EN55022, EN55024



Product code:

TRI17LD1-A767
