View larger
Marposs E50 - TFT-Ersatzmonitor
TOI8LB1-MRPEGA / TOI10LB1-MRPEGA
New
More info
These 8“ - 10" - 12" TFT monitors have been developed as a replacement for the 10“ - 12" - 14" CRTColor Monitor mounted in Marposs E50.
Our TFT is a Plug & Play solution, that means it is 100% compatible on the electrical and mechanical side.
This allows a quick and easy replacing without a specific technical knowledge and tooling.
|
Technical data: |
|
|
Operator panel / CNC |
Marposs E50 |
|
Original Monitor Code |
SL/801022101 (8") - SL/801222201 (10") - SL/801422301 (12") |
|
Display |
8“ - 10" - 12"TFT LCD active matrix / 800x600 |
|
Brightness |
300 cd/m2 |
|
Viewing angle |
140° H - 120° V |
|
Frequency range |
15-45 kHz horizontal, 50-75 Hz vertikal |
|
Connector |
CARD-EDGE |
|
Menu settings |
Via OSD (On Screen Display) |
|
Front panel |
Frontal Lexan Protection |
|
Mechanical dimension |
100% compatible to the original |
|
Operating voltage |
12 VDC |
|
Operating temperature |
-10°C to 55°C |
|
Manufactured according to |
EN55022, EN55024 |
|
|
|
|
Product code: |
TOI8LB2-MPERGA / TOI10LB1-MPERGA / TOI12LB1-MPERGA |
