TOE15DC1-A497
New
Availability date:
Amada Amnc - TFT-Ersatzmonitor
15" TFT Industriemonitor als Ersatz für den 15" CRT Monitor verbaut in Amada AmncEmpfänger :
* Pflichtfelder
oder Abbrechen
Amada Amnc - TFT-Ersatzmonitor
15" TFT Industriemonitor als Ersatz für den 15" CRT Monitor verbaut in Amada AmncFor questions regarding an order, thank you use the contact form
* Required fields
Cancel or
This 15“ TFT monitor has been developed as a replacement for the 15“ CRT Monitor mounted in Amada Amnc.
Our TFT is a Plug & Play solution, that means it is 100% compatible on the electrical and mechanical side.
This allows a quick and easy replacing without a specific technical knowledge and tooling.
Technical data: |
|
Operator panel / CNC |
Amada Amnc |
Display |
15“ TFT LCD active matrix / 1024x768 |
Brightness |
300 cd/m2 |
Viewing angle |
140° H - 125° V |
Frequency range |
15-45 kHz horizontal, 50-75 Hz vertikal |
Connector |
HD 15 M |
Menu settings |
Via OSD (On Screen Display) |
Front panel |
Frontal Lexan Protection |
Mechanical dimension |
100% compatible to the original |
Operating voltage |
100 - 240 VAC |
Operating temperature |
-10°C to 55°C |
Manufactured according to |
EN55022, EN55024 |
|
|
Product code: |
TOE15DC1-A497 |
